12 X7532098207

CONTENTS SRM-230

CONTENTS

The ECHO product you purchased has been factory pre-assembled for your convenience. Due to packaging

restrictions, shield installation and other assembly may be necessary.

After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or

missing parts. Use the contents list to check for missing parts.

*Some Echo units may be factory pre-assembled. The nylon line head, plastic debris shield, and mounting

hardware shown in the contents list are pre-assembled to the unit. Assembly tools are not supplied with

these units. The front handle may need to be re-positioned for comfortable operation.

____ - 1 - Power Head / Drive Shaft Assembly

____ - 1, Operator’s Manual

____ - 1, Safety Manual

____ - 1, Emission Control Warranty Statement

____ - 1, Warranty Registration Card

____ - 1, Safety Glasses

____ - 1, Echo Power Blend X

2-Stroke Oil Sample

*____ - 1, Nylon Trimmer Head

*____ - Assembly Tool(s)

*____ - 1, Plastic Shield

*____ - 1, Shield Plate

*____ - 3, 5mm x 16mm Screws (shield mount)
